B1-DHP

B1-DHP

0.00

HIGHWAY POWER CENTER

  • EEMAC 3R enclosure

  • Typically used for road lighting when associated with traffic control intersections with inside meter socket provision, when separate control of multiple contactors are required along with further continuous power circuits and meter is to be located within enclosure

  • EEMAC 4X construction allows for wash down as required

  • Fits up to con-force #4-0045 or HO #MK100 precast base

  • Marine grade aluminum - super durable ASA 61 grey powder coat finish

  • Pedestal mount style complete with bottom opening and mounting trim turned inward

  • Service entrance rated main breaker section 10kAIC at 250V (optional 22kAIC) c/w sealable and lockable cover

  • Mid mounted CDP 250A - 18cct Siemens P1 optional 30cct

Notes

  • Specify quantity and size of breakers and contactors at time of order

  • Available in B1-A series with contactor control in rear and space for various control ex. cameras etc.

Read more in the Product PDF
