PDC-K

PDC-K

0.00

WEATHERPROOF MAIN DISTRIBUTION CENTER

  • EEMAC 3R enclosure

  • Designed as a weatherproof, pad mount style, service entrance rated power distribution center when CT/PT metering is required with optional hydro supply pull section and load CDP is needed for distribution to multiple loads

  • Steel construction - ASA 61 grey

  • CT/PT section complete with hinged, sealable door

  • Rated 600V 3 phase 4 wire

  • Dead front interior door/covers

  • Double overlapping hinged outer doors complete with 3 point padlockable handle

  • Oil resistant gasket material inside doors

  • Hydro meter socket by others (sleeve included with assembly when hydro pull is supplied)

  • Safety soft, machine formed corners on driphood on top

  • Cross-brake style roof

  • Consult factory on kAIC

  • 3" bottom flange turned inwards

NOTES

  • Model #'s below are single tub style

  • Available in 208V & 460V up to 100kAIC

  • 1200A & 1600A 600V are standard with residual ground fault trips

  • For double tub add suffix 'D'
