WEATHERPROOF WALL MOUNT PANEL BOARD

  • EEMAC 3R enclosure

  • Designed as a heavy duty, weatherproof, combination panel and contactor, wall mount, single panel enclosure/assembly with bolt in style breakers for service or branch circuit exterior use and contactor section for individual control of various circuits

  • ASA 61 grey powder coat finish

  • Steel construction - code gauge

  • Rear mounting dimples - full top driphood c/w safety soft machine formed corners

  • Hinged outer gasketed door complete with clasp closers

  • Siemens 'P1' panel included MLO - 10kAIC

  • Tin plated aluminum bus material

  • Full ground bar

  • Fully assembled and CSA certified

Options

  • Seam welded EEMAC 12or 4

  • Aluminum or stainless EEMAC 3R or 4X

  • Various powder coat colours

  • Skid mounted

  • Copper bus material

  • Full cage and skid

  • Branch breakers and filler plates available

  • Main breaker service entrance style

  • Logic for contactor (specify)

  • 3 Point padlockable handle

  • 480V and 600V models Siemens 'P1'

  • 22kA and higher interrupting capacity

  • 400A to 1200A ratings

Notes

  • Maximum 4 qty. - 3P60A size contactors - for larger contactors consult factory

  • Available with multiple logic control as in Cartrols 1 to 5 or PEC etc. - specify logic and consult factory

  • Depending on contactors selected assembly depth may increase to 9" to accommodate HOA and contactor (consult factory)
