WEATHERPROOF WALL MOUNT PANEL BOARD

  • EEMAC 3R enclosure

  • Designed as a heavy duty, weatherproof, wall mount single panel enclosure/assembly with bolt in style breakers for service or branch circuit exterior use complete with optional device plates

  • ASA 61 grey powder coat finish

  • Steel construction - code gauge

  • Rear mounting dimples - full top driphood complete with safety soft machine formed corners

  • Hinged outer gasketed door complete with clasp closers

  • Siemens 'P1' panel included MLO - 10kAIC

  • Tin plated aluminum bus material

  • Full ground bar

  • Fully assembled and CSA certified

Options

  • Seam welded EEMAC 12or 4

  • Aluminumor stainlessEEMAC 3Ror 4X

  • Various powder coat colours

  • Skid-mounted

  • Full cage and skid

  • Copper bus material

  • Branch breakers and filler plates available

  • Main breaker service entrance style

  • 3 point padlockable handle

  • 480V, 600V models Siemens

  • Side mounted device plates - 9" deep assembly

  • 22kA and higher interrupting capacity

  • 400A to 1200A ratings

  • rear quick entry/exit box

  • Contactor assembly - see model #DLCR-C

Notes

  • When model #DP-A or #DP-B device plates are added depth goes to 9" on assembly

  • Depending on contactors selected, assembly depth

  • may increase 9" to accommodate HOA and contactor (consult factory)
