DCC-SP-COS

DCC-SP-COS

0.00

CUSTOMER CONNECTION CABINET - NON CT - 100kA BRACED

SPECIAL CUSTOM UNIT

  • EEMAC 3R enclosure

  • Designed as large body high capacity customer connection cabinet for interconnection of multiple line and load cable as is required for demarcation points between utility and customer and provision for limiter

  • Welded steel construction - ASA 61 grey powder coat finish

  • Double overlapping doors complete with hidden continuous hinge, 3 point, stainless steel, padlockable handle complete with rollers on top and bottom and 4" snow kick

  • Solid full-width inner brackets for bus support complete with continuous length bus bars mounted on insulators 100kA braced

  • Two DDL-250-T ground lugs - one per side on copper ground bus (min.)

Options

  • Wall mounting ears on top and bottom

  • Bottom fed style

  • Current limiters to 200kA

  • Voltages to 25kV

 Read more in the Product PDF
