SPECIAL EVENT POWER TIE IN DISCONNECT

• EEMAC 3R enclosure

• Special event tie in center for connection of portable function equipment where fast and easy connections are required.

• Single door compact unit complete with lockable non fused disconnect. Wall mounted style complete with 1" mounting ears

• ASA 61 grey powder coat finish

• Door is hinged complete with locking clasp.

• Safety soft, machine formed corners on driphood and cross brake style roof

• Camlocks are Crouse Hinds E1016 style heavy duty type 4 bolt shoulder mount 400A - 600V style complete with aluminum device mounting plate.

Options

• 480V and 600V styles

• Camlock micro switch to indicate insertion of plug enhances operator and system safety

• Master contactor style when all lugs must be installed before contactors can be activated

• Circuit breaker type disconnect - specify size

• Reverse feed option so it can be used as a generator tie in center (see D-GTB series)
