DMSB-TB-200

DMSB-TB-200

0.00

COMBINATION UTILITY MS/TERMINATOR

  • EEMAC 3R enclosure

  • Specifically designed to accept "large line or load" conductors as required by voltage drop or cable temperature restrictions per CEC #4-006 and #6-300

  • Assembly is designed to be wall or post mountable with unique capability for line or load style oversized cable terminations

  • Meter socket is 200A oversized style complete with #6-250 Cu/Al lugs

  • Left side internal cable riser section barriers service and load conductor and has simple padlockable outer dead front door complete with provision for customer utility lock

  • Terminal section is fitted with (2) #2-350 or (1) #2-500 Cu/Al and has (2) #2-2/0 ground lugs as standard (lugs can be easily interchanged - consult factory)

  • ASA 61 Grey EEMAC 3R weatherproof assembly

  • CSA certified cssembly

OPTIONS

  • Custom load-line lugs (meter socket cannot vary from #6-250)

  • Top entry hub (barrier then is deleted)

  • Top and bottom pole mounting ears

  • 5th jaw for 1 phase meter socket

NOTE

  • Always consult utility and local inspection for approval prior to ordering & installation
